Parameter
Value
GENERALS
Frequency range
FCC - CCIR - OIRT - JPN - CHN
Rated output power
30 W
Modulation type
Direct carrier frequency
Operational Mode
Mono, Stereo, Multiplex
Environmental working conditions
-10 °C to + 50 °C / 95% relative Humidity non condensing
Frequency programmability
From software, with 10 kHz steps
Frequency stability
WT from -10°C to 50°C
±1 ppm
Modulation capability
150 kHz Stereo, 180 kHz Mono/MPX
Pre-emphasis mode
0 μS, 50 μS (CCIR), 75 μS (FCC)
POWER REQUIREMENTS
AC Power Input
AC Supply Voltage
80 ÷ 260 VAC Full Range
Active Power Consumption
70 W
Overall Efficiency
42 %
Connector
VDE IEC Standard
MECHANICAL DIMENSIONS
Phisical Dimensions
L x H x W
483 mm x 44 mm x 394 mm
Weight
about 5,5 kg
Cooling
Forced, with internal fan
Acoustic Noise
< 58 dBA
AUDIO INPUTS
Left/Mono & Right
10 Kohm or 600ohm (XLR F) Level:-13 to +13 dBu
MPX
10 Kohm or 50 ohm (BNC) Level: -13 to +13 dBu @ 75 KHz FM
SCA/RDS
10 Kohm (2x BNC) Level: -8 to +13 dBu @ 75 KHz FM
AES/EBU
110 (XLR F) Level: 0 to -10 dBfs @ 75 KHz FM
OUTPUTS
RF Output
50 ohm (N type)
RF Monitor
50 ohm (BNC) approx. -30 dBc
Pilot output
>5 Kohm (BNC) approx.1Vpp
FUSES
On Mains
1 External fuse F 3,15 T - 5x20 mm
