Ambient temperature: -40 - +65°C (+80°C for max. 2 hours).
DIN-approved units: -40 - +65°C (+80°C for max. 2 hours).
Max. working pressure = 32 bar, KP 6 = 46.5 bar.
Max. test pressure = 35 bar, KP 6 = 46.5 bar.
Contact load, AC:
AC1: 16 A, 400 V.
AC3: 16 A, 400 V.
AC15: 10 A, 400 V.
Max. starting current (L.R.): 112 A, 400 V.
Contact load, DC:
DC13: 12 W, 220 V control current.
