TYPE CODE
KPS37
WEIGHT
0.951 Kg
AMB. TEMP. NOTE
80 °C/176 °F for max 120 min
AMBIENT TEMP.
-40 - 70 °C
AMBIENT TEMP.
-40 - 158 °F
APPROVAL
ABS, BV, CCC, CCS, CE, DNV, EAC, GL, KRS, LR, LVD, NKK, RINA, RMRS, RoHS, RoHS China, TYSK, UL
CONTACT FUNCTION
SPDT gold
CONTACT RATING
AC1=10 A, 440 V
CONTACT RATING
AC15=4 A, 440 V
CONTACT RATING
AC3=6 A, 440 V
CONTACT RATING
DC13=12 W, 220 V
CONTACT RATING
for gold 1…30 mA, 5...30 V
CONTACT RATING
LR max. 50 A
DIFF.
0,85 - 2,50 bar
DIFF.
12,00 - 36,00 psi
EAN NO.
5702423146833
ELECTR. CONN. COMMENTS
Metal cable gland
ELECTR. CONN. MALE/FEMALE
Female
ELECTR. CONN.
DIN 40430 Pg 13.5
ELECTR. CONN.
Screwed cable entry
EN 60947 ELECTRICAL PROPERTIES
Insulation: 400V
EN 60947 ELECTRICAL PROPERTIES
Pollution degree: 3
EN 60947 ELECTRICAL PROPERTIES
Rated impulse voltage: 4 kV
EN 60947 ELECTRICAL PROPERTIES
Short circuit prot, fuse: 16A
EN 60947 WIRING PROPERTIES
Flex, ferrules: 0.5-1.5 mm2
EN 60947 WIRING PROPERTIES
Flex, no ferrules: 0.7-2.5 mm2
EN 60947 WIRING PROPERTIES
Solid/stranded: 0.75-2.5 mm2
ENCLOSURE RATING
IP67
IDENTICAL PROD.
060-411266
MAX. TEST PRESSURE
27,0 bar
MAX. TEST PRESSURE
392,0 psig
MAX. WORKING PRESSURE
22,0 bar
MAX. WORKING PRESSURE
319 psig
PACK FORMAT
Multi pack
PRESSURE CONN. STD.
ISO 228-1
PRESSURE CONN. TYPE
G - 1/4 Female
PRESSURE SENSING ELEM.
Bellows
PRODUCT ACCESSORIES
Switches accessories
PROD. DESCRIPTION
Pressure switch
PROD. GROUP
Switches and thermostats
PROD. NAME
Pressure switch
PACK QTY.
8 PC
REGUL. RANGE
6,00 - 18,00 bar
REGUL. RANGE
0,60 - 1,80 MPa
REGUL. RANGE
87,00 - 261,00 psig
RESET
AUTO
SERVICEABLE
No
UL APPROVAL FILE NAME
E73170
